Appendix 65
FILE LOCATION: FILE LOCATION: FILE LOCATION: FILE LOCATION: S:\SYSTEMS\Pong\solutions\Lavaca A01\English\7328Vc41.fm
D E L L C O N F I D E N T I A L – P R E L I MI NA RY 4 / 1 6 / 0 1 D E L L C O N F I D E N T I A L – P R E L I MI NA RY 4 / 1 6 / 0 1 D E L L C O N F I D E N T I A L – P R E L I MI NA RY 4 / 1 6 / 0 1 D E L L C O N F I D E N T I A L – P R E L I MI NA RY 4 / 1 6 / 0 1
Panel (typical)
Backlight 1.3 W
3.4 W using battery; 4.9 W using AC
adapter
Controls brightness can be controlled through key
combinations
Keyboard
Number of keys 87 (U.S., Canada, and locations that use
traditional Chinese); 88 (Europe); 90
(Japan)
Key travel 2.7 ± 0.3 to 0.4 mm (0.11 ± 0.016 inch)
Key spacing 19.05 ± 0.3 mm (0.75 inch ± 0.012 inch)
Layout QWERTY/AZERTY/Kanji
Touch Pad
Interface PS/2 compatible
X/Y position resolution
(graphics table mode) 240 cpi
Size:
Thickness 2.00 mm (0.08 inch) at highest component
Width 64.88 mm (2.55 inch)
Height 48.88-mm (1.92-inch) rectangle with
0.5-mm (0.02-inch) tabs
Weight 6.5 g (0.23 ounce) ± 0.5 g (0.001 ounce)
Power:
Supply voltage 5 V ± 0.5 VDC
Supply current 25 mA (maximum operating current) for
track stick and touch pad combined
ESD in accordance with IEC-801-2
Display (continued)
