Removing a Front-Access SCSI Hard Drive (Non-Hot-Plug)
1. Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
2. Remove the bezel. See " Removing the Bezel " in "Troubleshooting Your System."
3. Open the hard-drive carrier handle to release the drive. See Figure 7 -11 .
4. Slide the hard drive out until it is free of the drive bay.
Figure 7-11. Removing or Installing a SCSI Hard-Drive Carrier
Installing a Front-Access SCSI Hard Drive (Non-Hot-Plug)
1. Turn off the system, including any attached peripherals, and disconnect the system from the electrical outlet.
2. Remove the bezel. See " Removing the Bezel " in "Troubleshooting Your System."
3. Open the hard-drive carrier handle. See Figure 7 -11 .
4. Insert the hard-drive carrier into the drive bay. See Figure 7 -11 .
5. Close the hard-drive carrier handle to lock it in place.
NOTICE: To prevent data loss, you must shut down the system before removing a SCSI drive carrier, unless a SCSI RAID controller is connected to the
SCSI backplane. See " Hot-Plug SCSI Hard Drives " for information on hot-plug drive requirements and operation.
NOTICE: Do not insert a hard-drive carrier and attempt to lock its handle next to a partially installed carrier. Doing so can damage the partially installed
carrier's shield spring and make it unusable. Ensure that the adjacent drive carrier is fully installed.
