Fingerprint Reader
Dell™ Latitude™ E5410 Discrete Service Manual
Removing the Fingerprint Reader
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the battery from the computer.
3. Remove the access panel from the computer.
4. Remove the optical drive from the computer.
5. Remove the LED cover from the computer.
6. Remove the keyboard from the computer.
7. Remove the display assembly from the computer.
8. Remove the LED board from the computer.
9. Remove the palm rest from the computer.
10. Remove the screw that secures the fingerprint reader to the palm rest.
11. Lift up the fingerprint reader cover at an angle and remove.
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
