Using the TV Menu 31
FILE LOCATION: C:\Documents and Settings\parksh2\¼ŸЭ¡ »¦³И\Ч¢¡ж\Dell\W3202_3706MC_EMEA_OM\MC_EMEA_proof
D E L L C O N F ID E N T IA L – P R E L IM I N A RY 1 0 / 2/ 0 5 – F O R PR O O F O N LY
If you select Personal, you can adjust the individual audio levels, such as Treble, Bass and Balance.
TV Out Volume — Select Fixed if you want to adjust the volume using the remote or volume
control on an attached audio receiver. Select Variable if you want to adjust the volume using the
TV remote or front panel buttons. Using Variable adjusts the TV volume out not the volume on an
attached audio receiver.
Use
Sound Mode to select Mono, Stereo, Dual1, Dual2, Nicam, Nicam-ST, Nicam-D1 and
Nicam-D2.
Use
Mute to turn the TV sound on or off and use Speaker Out to turn on or off the sound from the
speaker.
PIP/POP/PBP
You can view two active sources simultaneously using Picture-In-Picture (PIP), Picture-Outside-
Picture (POP), or Picture-By-Picture (PBP).
The remote control offers the following
PIP/POP/PBP options:
• Use the PIP button or the POP/ PBP
button on the remote control to turn on and
off PIP, POP, and PBP.
• If you are in PIP, or PBP mode, use the
SWAP button on the remote control to
switch between the two windows.
• Use the POS button on the remote to
change which corner of the screen the PIP
window appears.
In the TV Menu, you can adjust the
Transparency, the Size, and H (horizontal) and
V (vertical) position of the PIP windows. When
you are selecting the horizontal orientation, -
moves the window left and + moves the window to the right. When you are adjusting the vertical
orientation, 0 is at the top of the screen and 100 is at the bottom of the screen.
For
POP, you can select from three different POP options:
• POP1 — One large POP window to the left and a smaller, centered window on the right.
• POP3 — One large POP window to the left and three smaller, vertically-aligned windows on
the right.
• POP12 — One large, centered POP window surrounded by twelve smaller windows.
POP Scan Mode allows you to select Sequential or Float. Float mode plays the source for selected
channels that appear in the windows. Sequential rotates through each window and plays all of the
preselected channels. The rotation runs through all the available channels before it starts again at
the lowest channel.
