10. Secure unused antenna cables in the protective mylar sleeve.
11. Replace the palm rest. See Replacing the Palm Rest .
12. Slide the battery into the battery bay, until it clicks in place and slide the battery-lock latch to the lock position.
13. Install the drivers and utilities for your computer, as required. For more information, see the Dell Technology Guide.
Back to Contents Page
WWAN (2 antenna cables)
Main WWAN (white triangle)
Auxiliary WWAN (black triangle)
white with gray stripe
black with gray stripe
WLAN (2 or 3 antenna cables)
Main WLAN (white triangle)
Auxiliary WLAN (black triangle)
white
black
NOTE: If you are installing a communication card from a source other than Dell, you must install the appropriate drivers and utilities. For more
information, see the Dell Technology Guide.
