Processor Heat-Sink | 63
Replacing the Processor Heat-Sink
CAUTION: Incorrect alignment of the processor heat-sink can cause damage to
the system board and processor.
Procedure
1 Clean the thermal grease from the bottom of the processor heat-sink and
reapply it.
NOTE: The original thermal grease can be reused if the original processor and
processor heat-sink are reinstalled together. If either the processor or the
processor heat-sink is replaced, use the thermal grease provided in the kit to
ensure that thermal conductivity is achieved.
2 Align the captive screws on the processor heat-sink with the screw holes on the
system board.
3 In sequential order (indicated on the processor heat-sink), tighten the
captive screws that secure the processor heat-sink to the system board.
Postrequisites
1 Replace the system-board shield. See "Replacing the System-Board Shield" on
page 36.
2 Replace the back cover. See "Replacing the Back Cover" on page 20.
3 Replace the stand. See "Replacing the Stand" on page 18.
4 Replace the stand cover. See "Replacing the Stand Cover" on page 16.
5 Follow the instructions in "After Working Inside Your Computer" on page 13.
