42 | TV-Tuner Card (Optional)
Procedure
1 Disconnect the TV-tuner-card cable from the connector on the TV-tuner card.
2 Remove the screw that secures the TV-tuner card to the system-board connector.
3 Lift the TV-tuner card away from the system-board connector.
CAUTION: When the TV-tuner card is not in the computer, store it in protective
antistatic packaging. See "Protecting Against Electrostatic Discharge" in the
safety instructions that shipped with your computer.
1 TV-tuner-card cable 2 screw
3 TV tuner card
1 2
3
