1 AC adapter
2 AC adapter connector
1. Complete the steps in " Before You Dock for the First Time ."
2. Save and close any open files and exit any open programs.
3. If you have not already done so, connect the AC adapter to the AC adapter connector on the APR, and plug the AC
adapter power cable in to an electrical outlet.
4. Place the APR so that there is enough flat space in front of it to completely support the computer when the computer is
docked.
5. Ensure that the slide lock is in the unlocked position (toward the back of the APR).
6. Hold the computer by its sides and center it against the backstop at the front of the APR.
7. Lower the computer and move it slightly from side to side until you feel it seated on the alignment posts.
NOTICE: To avoid damaging the computer display, press down only over the hinges.
8. Push over the hinges until the computer until the docking connector clicks into place.
