Installing the Processor Thermal-Cooling Assembly
1. Slide the hole in the bottom cooling assembly plate over the video connector and carefully rotate the plate into place against the bottom of the system
board. Its holes should line up with holes in the system board.
2. Seat the microprocessor thermal-cooling assembly in place. All four screws should match up with the screw holes in the system board and the bottom
cooling assembly plate. The fan should overhang the board to the right of the video connector.
3. Reattach the fan power cord.
4. Tighten the four captive screws labeled "1" through "4" in consecutive order.
Back to Contents Page
NOTICE: If the screws are not tightened in their numbered order, the processor may be damaged.
