Dell PowerEdge 1800 - Manual (Page 3)

USB Two 4-pin, USB 2.0-compliant
Video 15-pin VGA
Front
USB two 4-pin, USB 2.0 compliant
Internally accessible
SCSI channel one 68-pin U320 SCSI
SATA channel two 7-pin SATA
Video
Video type ATI Radeon 7000-M video controller; VGA connector
Video memory 16 MB
Power
AC power supply (per power supply)
Wattage 675 W
Voltage 100–240 VAC, 50–60 Hz
Heat dissipation 2217 BTU/hr maximum
Output hold up time 20 ms minimum
Maximum inrush current Under typical line conditions and over the entire
system ambient operating range, the inrush current
may reach 55 A at 10 ms or less, or 25 A at 150 ms or
less.
Battery
System battery CR 2032 3.0-V lithium-ion coin cell
Physical
Tower with bezel
Height 45.0 cm (17.7 inches)
Width 21.8 cm (8.6 inches)
Width (with feet extended) 32.9 cm (12.9 inches)
Depth 57.41 cm (22.6 inches)
Weight (maximum configuration) 34.5 kg (76 lb), maximum configuration
Rack with bezel
Height 21.8 cm (8.6 inches)
Width (with rack mounts) 48.02 cm (18.9 inches)
Width (without rack mounts) 43.5 cm (17.1 inches)
Depth 57.41 cm (22.6 inches)
Weight (maximum configuration) 34.5 kg (76 lb), maximum configuration
Environmental
NOTE: For additional information about environmental measurements for specific system configurations, go
to www.dell.com/environmental_datasheets.
Temperature
Operating 10° to 35°C (50° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity
Operating 20% to 80% (noncondensing)
Storage 5% to 95% (noncondensing)
Maximum vibration
Operating 0.25 G (half-sine wave) at a sweep of 3 to 200 MHz
for 15 minutes
Storage 0.5 G at 3–200 Hz for 15 min
Maximum shock
Operating six consecutively executed shock pulses in the
positive and negative x, y, and z axes (one pulse on
each side of the system) of 36 G for up to 2.6 ms
