Hang grease clip from bottom of firebox and place grease cup into
grease clip.
Grease clip
80000271
CAUTION
Failure to install grease clip and cup
will cause hot grease to drip from
bottom of grill with risk of fire or
property damage.
Grease cup
80000270
14
Attach tank retainer wire to left side support brace using one
1/4-20x1¼” carriage bolt and one 1/4-20 tee knob. Do not
fully tighten until LP cylinder is installed.
Tank retainer wire
80012766
1/4-20 Tee Knob
Qty. 1
1/4-20x1¼”
Carriage Bolt
Qty. 1
463666508 • 19
