16
Internal Card with Bluetooth
Wireless Technology
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 11. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
If you ordered a card with Bluetooth wireless technology with your computer,
it is already installed.
Removing the Bluetooth Card
Prerequisites
1 Remove the base cover. See "Removing the Base Cover" on page 15.
2 Remove the battery. See "Removing the Battery" on page 17.
3 Remove the center-control cover.
See "Removing the Center-Control Cover" on page 33.
4 Remove the keyboard. See "Removing the Keyboard" on page 37.
5 Remove the palm-rest assembly.
See "Removing the Palm-Rest Assembly" on page 41.
Procedure
1 Disconnect the Bluetooth-card cable from the connector on the system
board.
2 Remove the screw that secures the Bluetooth card to the computer base.
3 Note the routing of Bluetooth-card cable and remove the cable from the
routing guides.
4 Lift the Bluetooth card along with the cable off the computer base.
Internal Card with Bluetooth Wireless Technology 65
