4. To remove the docking board:
a. Flip the board [1].
b. Disconnect the docking board connector cable from the system board by lifting the cable-
release tab [2].
c. Lift and remove the docking board from the computer chassis [3].
Installing the Docking Board
1. Connect the docking board connector cable to the system board.
2. Flip the docking board and seat it on the slot.
3. Tighten the screws to secure the docking board.
4. Connect the antenna cables to the docking board.
5. Install:
a. bottom cover
b. battery
6. Follow the procedures in After Working Inside Your Computer .
Removing the Heatsink
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove:
