Removing and Replacing Parts 33
3 Reinstall the 4-mm screw that secures the flex cable mounting bracket
to the top cover.
4 Starting on the left side, use a magnetic screwdriver to reinstall the six
3-mm screws that secure the display panel in the top cover.
5 Reinstall the display flex cable strain-relief screw and reconnect the
flex cable to the graphics card.
6 Reinstall the display assembly bezel.
Removing the Display Latch
Re mo v i ng th e Di s p l ay L a t ch
1 Remove the hinge cover .
2 Detach the display flex cable from the strain relief and the graphics
card.
3 Remove the display assembly bezel .
4 Remove the display panel from the top cover .
5 Remove the display latch by unsnapping the latch and captive spring.
