System Capacity
(in GB)
DIMM Size (in
GB)
Number of
DIMMs
DIMM Rank, Organization,
and Frequency
DIMM Slot Population
NOTE: 16 GB DIMMs must be
installed in slots numbered A1, A2,
A3, A4, A5, A6, A7, and A8 and 8
GB DIMMs must be installed in
slots A9 and A11.
384 32 12 LRDIMM, x4, 1333 MT/s A1, A2, A3, A4, A5, A6, A7, A8, A9, A10,
A11, A12
Table 2. Memory Configurations—Two Processors
System
Capacity (in
GB)
DIMM Size (in
GB)
Number of
DIMMs
DIMM Rank,
Organization, and
Frequency
DIMM Slot Population
16 2 8 1R, x8, 1333 MT/s,
1R, x8, 1600 MT/s A1, A2, A3, A4
B1, B2, B3, B4
32 2 16 1R, x8, 1333 MT/s A1, A2, A3, A4, A5, A6, A7, A8
B1, B2, B3, B4, B5, B6, B7, B8
32 4 8 2R, x8, 1333 MT/s,
2R, x8, 1600 MT/s A1, A2, A3, A4
B1, B2, B3, B4
64 4 16 2R, x8, 1333 MT/s A1, A2, A3, A4, A5, A6, A7, A8
B1, B2, B3, B4, B5, B6, B7, B8
8 8 2R, x4, 1333 MT/s,
2R, x4, 1600 MT/s A1, A2, A3, A4
B1, B2, B3, B4
96 4 24 2R, x8, 1333 MT/s A1, A2, A3, A4, A5, A6, A7, A8, A9,
A10, A11, A12
B1, B2, B3, B4, B5, B6, B7, B8, B9,
B10, B11, B12
8 12 2R, x4, 1333 MT/s,
2R, x4, 1600 MT/s A1, A2, A3, A4, A5, A6
B1, B2, B3, B4, B5, B6
128 8 16 2R, x4, 1333 MT/s A1, A2, A3, A4, A5, A6, A7, A8
B1, B2, B3, B4, B5, B6, B7, B8
16 8 2R, x4, 1333 MT/s,
2R, x4, 1600 MT/s A1, A2, A3, A4, B1, B2, B3, B4
160 8 20 2R, x4, 1333 MT/s A1, A2, A3, A4, A5, A6, A7, A8, A9,
A11
B1, B2, B3, B4, B5, B6, B7, B8, B9,
B11
16 and 8 12 2R, x4, 1333 MT/s,
2R, x4, 1600 MT/s A1, A2, A3, A4, A5, A6,
B1, B2, B3, B4, B5, B6
