Removing the Display Back-
Cover and Antenna Assembly
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before Working Inside Your Computer . After working inside your
computer, follow the instructions in After Working Inside Your
Computer . For more safety best practices, see the Regulatory
Compliance home page at dell.com/regulatory_compliance.
Prerequisites
NOTE: These instruction are applicable only to laptops with a non-
touchscreen display.
1 Remove the battery .
2 Remove the base cover .
3 Follow the procedure from step 1 to step 3 in removing the hard drive .
4 Follow the procedure from step 1 to step 2 in removing the optical drive .
5 Remove the keyboard .
6 Remove the palm rest .
7 Remove the display assembly .
8 Remove the display bezel .
9 Remove the camera .
10 Follow the procedure from step 1 to 3 in removing the display panel .
Procedure
1 On the display back-cover and antenna assembly, peel off the tape that
secures the antenna cables to the display back-cover.
2 Remove the antenna cables from the routing guides on the display back-
cover.
