Removing the Hard Drive | 25
Procedure
1 Remove the screws that secure the hard-drive assembly to the computer base.
2 Using the pull tab, slide the hard-drive assembly towards the side of the computer
to disconnect the hard-drive assembly from the system board.
3 Using the pull tab, lift the hard-drive assembly off the computer base.
1 pull-tab 2 hard-drive assembly
3 screws (3)
1
2
3
