Dell 6 GBps SAS HBA - Manual (Page 16)

16 Hardware Installation
Figure 3-3. Connecting the Cable for 6 Gbps SAS HBA
10 Replace the cover of the system.
For more information on closing the system, see your system’s Hardware
Owner’s Manual or the User’s Guide.
11 Reconnect the power cable(s) and network cables, and then turn
on the system.
NOTE: For more information on connecting your 6 Gbps SAS HBA to an RBOD
enclosure or external tape device see your system’s Hardware Owner’s Manual on
the Dell Support website at support.dell.com/manuals.
NOTE: The 6 Gbps SAS HBA and Internal Tape Adapter cards do not support
installing an operating system on a disk attached to the 6 Gbps SAS HBA or a tape
drive.
NOTE: Hard drives are not supported on the Internal Tape Adapter.
1 6 Gbps SAS HBA 2 Cable from the external tape device or
enclosure
1
2
