12

About Your Monitor

About Your Monitor

13

Electrical Specifications

Weight without stand assembly
(For wall mount or VESA mount

3.00 kg (6.75 lb)

considerations - no cables)
Weight of stand assembly

1.03 kg (2.27 lb)

Video input signals

Analog RGB, 0.7 Volts +/-5%, positive polarity at
75 ohm input impedance
Digital DVI-D TMDS, 600mV for each
differential line, positive polarity at 50 ohm input
impedance

Synchronization input
signals

Separate horizontal and vertical
synchronizations, polarity-free TTL level, SOG
(Composite SYNC on green)

AC input voltage/
frequency/current

100 to 240 VAC/50 or 60 Hz + 3 Hz/1.5 A (Max.)

Inrush current

120 V:30 A (Max.)
240 V:60 A (Max.)

Physical Characteristics

Connector type

15-pin D-subminiature, blue connec­
tor; DVI-D, white connector

Signal cable type

Digital: Detachable, DVI-D (E2414H
only), Solid pins.
Analog: Detachable, D-Sub, 15 pins.

Dimensions (with stand)
Height

418.3 mm (16.47 inches)

Width

570.0 mm (22.44 inches)

Depth

164.2 mm (6.46 inches)

Dimensions (without stand)
Height

337.5 mm (13.29 inches)

Width

570.0 mm (22.44 inches)

Depth

46.5 mm (1.83 inches)

Stand dimensions
Height

318.7 mm (12.55 inches)

Width

180.6 mm (7.11 inches)

Depth

164.2 mm (6.46 inches)

Weight
Weight with packaging

5.87 kg (12.94 lb)

Weight with stand assembly and
cables

4.48 kg (9.88 lb)

Environmental Characteristics

Temperature

Operating

0 °C to 40 °C

Non-operating

Storage: -20 °C to 60°C (-4 °F to 140 °F)

Shipping: -20 °C to 60°C (-4 °F to 140 °F)

Humidity

Operating

10% to 80% (non-condensing)

Non-operating

Storage: 5% to 90% (non-condensing)

Shipping: 5% to 90% (non-condensing)

Altitude

Operating

5,000 m (16,400 ft) max

Non-operating

12,191 m (40,000 ft) max

Thermal dissipation

238.85 BTU/hour (maximum)

102.36 BTU/hour (typical)

Power Management Modes

If you have VESA’s DPM™ compliance display card or software installed
in your PC, the monitor can automatically reduce its power consumption
when not in use. This is referred to as Power Save Mode. If the computer
detects input from keyboard, mouse, or other input devices, the monitor
automatically resumes functioning. The following table shows the power
consumption and signaling of this automatic power saving feature:

VESA Modes Horizontal

Sync

Vertical

Sync

Video

Power

Indicator

Power Consump­

tion

Normal

operation

Active

Active

Active

White

20 W (typical)/30 W

(maximum)

Active-off

mode

Inactive

Inactive Blanked Glowing

White

Less than 0.5 W

Switch off

-

-

-

Off

Less than 0.5 W

The OSD will only function in the normal operation mode. When any button
