Dell E2414H Monitor User Manual

Page 14



Operating the Monitor



Brightness

Brightness adjusts the luminance of the backlight.
Press the

button to increase brightness and

Press the

button to decrease brightness (min 0 ~

max 100).
NOTE: Brightness control will be greyed out during
“Screen dim” in PowerNap option when screen
saver is activated.

Contrast

Adjust Brightness first, and then adjust Contrast only
if further adjustment is necessary.
Press the

button to increase contrast and Press

the

button to decrease contrast (min 0 ~ max

100).
The Contrast function adjusts the degree of
difference between darkness and lightness on the
monitor screen.

AUTO ADJUST Even though your computer recognizes your

monitor on startup, the Auto Adjustment function
optimizes the display settings for use with your
particular setup.
Auto Adjustment allows the monitor to self-adjust
to the incoming video signal. After using Auto
Adjustment, you can further tune your monitor by
using the Pixel Clock and Phase controls under

Displays Settings.

The following dialog appears on a black screen as
the monitor automatically adjusts to the current
input:

NOTE: In most cases, Auto Adjust produces the
best image for your configuration.

NOTE: AUTO ADJUST option is only available when
you are using the analog (VGA) connector.
