1. Connect your antenna or Cable TV signal to the IN FROM ANT (enna) plug on the

VCR.

2. Connect the OUT TO TV plug on the VCR to the 75 ohm plug on the TV (connecting

cable supplied with the VCR).

3. Refer to the owner's manual included with your VCR for other possible connections

and TV/VCR operating details.

Connecting to DVD/VCD/VCR/CATV BOX

Connect devices with cables provided. Select Composite or S-Video input from On Screen
Display (OSD) Menu. Refer to the Controls and Indicators section in this document for more
information on the OSD. S-Video Source generally yields better video performance than
composite.

Connect device with cables provided. Select Component input from OSD Menu. For optimal
performance use YPbPr for HDTV formats.
