3. Follow the instructions from step 2 to step 3 in Replacing the Antenna-In Connector .
4. Route the antenna-in connector cable and infrared (IR) blaster connector cable through the routing guides on the system-board shield.
5. Connect the IR blaster connector cable to the connector (CIR Receiver) on the system board.
6. Connect the antenna-in connector cable to the connector on the TV tuner card.
7. Carefully turn the system-board shield over and align the screw holes on the system-board shield with the screw holes on the chassis.
8. Replace the four screws that secure the system-board shield to the chassis.
9. Replace the rear stand cover (see Replacing the Rear Stand Cover ).
10. Follow the instructions from step 4 to step 7 in Replacing the Front Stand .
11. Replace the back cover (see Replacing the Back Cover ).
12. Connect your computer and all attached devices to electrical outlets, and turn them on.
Back to Contents Page
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
