4.

Adhere the silver foil on the processor heat-sink.



5.

Connect the processor heat-sink fan cable to the connector (CPU FAN) on the system board.



6.

Replace the system-board shield (see

Replacing the System-Board Shield

).




7.

Replace the rear stand cover (see

Replacing the Rear Stand Cover

).




8.

Follow the instructions from

step 4

to

step 7

in

Replacing the Front Stand

.




9.

Replace the back cover (see

Replacing the Back Cover

).





10.

Connect your computer and all attached devices to electrical outlets, and turn them on.

Back to Contents Page



CAUTION:

Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may

result in damage to the computer.
