84 Media-Card Reader Board
9 Lift the media-card reader board away from the computer base.
Replacing the Media-Card Reader Board
1 Follow the instructions in "Before You Begin" on page 9.
2 Align the media-card reader board with the alignment poles on the
computer base.
3 Replace the screw that secures the media-card reader board to the
computer base.
4 Slide the cable into the connectors on the system board and the media-
card reader board, and then press down the securing latches.
5 Replace the palm-rest assembly. See "Replacing the Palm-Rest Assembly"
on page 38.
1 screw 2 media-card reader board
3 media-card reader board cable connectors (2)
2
1
3
