Keyboard
Dell™ Latitude™ 100L Service Manual
Removing the Keyboard
CAUTION:
Before working inside your Dell™ computer, read the safety instructions in your System
Information Guide.
CAUTION:
To prevent static damage to components inside your computer, discharge static electricity from
your body before you touch any of your computer's electronic components. You can do so by touching an
unpainted metal surface.
1. Follow the instructions in "
Before Working Inside Your Computer
2. Use a small flat-blade screwdriver or plastic scribe to lift the notched right edge of the hinge cover, and pry the cover
loose from the hinges and computer base.
1 hinge cover
Y4006
2 notched edge
3. Lift the hinge cover up and away from the hinges and computer base.
4. Remove the four M2 x 3-mm keyboard screws.
