Latitude™ E6420 XFR Service Manual

Page 27

12 Keyboard Cover

12.1 Removing the Keyboard Cover

CAUTION:

Before you begin any of the procedures in this section, follow the safety

instructions that shipped with your computer.

1. Follow the procedures in Before Working on Your Computer.
2. Remove the two M2.5 x 5-mm screws from the keyboard cover.

1 Keyboard Cover 2 M2.5x5 mm (2)

3. Remove the keyboard cover.

12.2 Replacing the Keyboard Cover

CAUTION:

Before you begin any of the procedures in this section, follow the safety

instructions that shipped with your computer.

1. Place keyboard cover on system.
2. Add the two M2.5 x 5-mm screws to secure the keyboard cover.
3. Follow the procedures in After Working on Your Computer.
