CHAPTER 13: DISPLAY
Replacing the AlienHead Board
Align the AlienHead board with the tab on the display back cover and slide it
1.
into position.
Replace the screw that secures the AlienHead board to the display back
2.
cover.
Replace the display back cover (see “Replacing the Display Back Cover” on
3.
page 58).
Replace the display assembly (see “Replacing the Display Assembly” on
4.
page 55).
Replace the magnesium cover (see “Replacing the Magnesium Cover” on
5.
page 51).
Replace the left and right brackets (see “Replacing the Brackets” on page
6.
47).
Replace the palm rest (see “Replacing the Palm Rest” on page
7.
44).
Replace the keyboard (see “Replacing the Keyboard” on page
8.
39).
Replace the center control cover (see “Replacing the Center Control Cover”
9.
on page 35).
Replace the battery pack (see “Replacing the Battery Pack” on page
10.
11).
CAUTION: Before turning on the computer, replace all screws and ensure
that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
