CHAPTER 13: DISPLAY
Replacing the Display Back Cover
Align the display back cover with the back of the display assembly and slide
1.
it into position.
Connect the AlienHead cable to the connector.
2.
Replace the two screws that secure the display back cover with the display
3.
assembly.
Slide the display back cover door in place.
4.
Turn the display assembly over and replace the two screws that secure the
5.
display back cover door to the display assembly.
Replace the display assembly (see “Replacing the Display Assembly” on
6.
page 55).
Replace the magnesium cover (see “Replacing the Magnesium Cover” on
7.
page 51).
Replace the left and right brackets (see “Replacing the Brackets” on page
8.
47).
Replace the palm rest (see “Replacing the Palm Rest” on page
9.
44).
Replace the keyboard (see “Replacing the Keyboard” on page
10.
39).
Replace the center control cover (see “Replacing the Center Control Cover”
11.
on page 35).
Replace the battery pack (see “Replacing the Battery Pack” on page
12.
CAUTION: Before turning on the computer, replace all screws and ensure
that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
