164

Specifications

5-in-1 Media Memory Card Reader

5-in-1 media memory card controller Ricoh R5C832

5-in-1 media memory card connector 5-in-1 combo card connector

Cards supported

MS
MS Pro
SD/SDIO
MMC
xD

5-in-1 media memory card connector
size

36.8 x 29.3 x 4.75 mm

Memory

Memory module connector

two SODIMM connectors

Memory module capacities

256 MB, 512 MB, 1 GB, and 2 GB

Memory type

1.8-V SODIMM DDR-2

Minimum memory

256 MB

Maximum memory

4 GB

Ports and Connectors

Audio

microphone/line-in connector, two
headphone connectors

NOTE:

You can use the microphone/line-in

and headphone connectors to switch to 5.1
surround sound mode (see "Sound Modes" on
page 68).

IEEE 1394a

4-pin serial connector

Mini-Card

two Type II Mini-Card slots

Modem

RJ-11 port

Network adapter

RJ-45 port

S-video TV-out

7-pin mini-DIN connector (optional adapter
cable(s) with S/PDIF, S-video, composite
video via dongle, and component video
connectors)

USB

four 4-pin USB 2.0-compliant connectors

Video

15-hole connector
