Loading Print Media
Proper print media loading helps prevent jams and ensures trouble-free printing.
Before loading print media, identify the recommended print side of the print media. This information is usually on the print media package.
Loading the Multipurpose Feeder
Loading Print Media in Optional Trays
Multipurpose Feeder
Capacity
The maximum stack height is 16 mm (0.6 in.). The multipurpose feeder can hold approximately:
l
150 sheets of 75 g/m
2
(20 lb) paper
Print Media Dimensions
The multipurpose feeder accepts print media within the following dimensions:
l
Width -- 90 mm to 215.9 mm (3.5 in. to 8.5 in.)
l
Length -- 139.7 mm to 355.6 mm (5.5 in. to 14 in.)
Loading the Multipurpose Feeder
In addition to plain paper, the multipurpose feeder can use various other sizes and types of print media such as envelopes, and transparencies.
1.
Gently pull open the multipurpose feeder cover.
2.
Slide the width guides to the edge of the tray. The width guides should be fully extended.
