23 Installation |
12 Snap the UPS front cover into place (see Figure 14).
Figure 14. Installing the UPS Front Cover
Installing the EBM
NOTE: A small amount of arcing may occur when connecting an EBM to the UPS. This is normal and will not
harm personnel. Insert the EBM cable into the UPS battery connector quickly and firmly.
To install the optional EBM:
1 Plug the EBM cable into the UPS battery connector (see Figure 15).
Figure 15. EBM Installation
