13
Tank retainer wire
LP CYLINDER IS SOLD SEPARATELY. Fill and leak check the cylinder before attaching to grill and regulator (see Use &
Care section). Once cylinder has been filled and leak checked, place cylinder into notches in tank support bracket. Make
sure cylinder valve is facing front of grill. Slide tank retainer wire over cylinder collar and tighten tee knob. Regulator
hose should be above side support brace.
See Use & Care section of this manual to perform the “Burner Flame
Check” and for important safety instructions before using.
CAUTION
Cylinder valve must face to front of cart once
tank is attached. Failure to install cylinder
correctly may allow gas hose to be damaged
in operation, resulting in the risk of fire.
LP Cylinder
(not included)
Always keep LP cylinders in
upright position during use,
transport, and storage.
Regulator
Tank
