Replacing the Optical Drive
1. Follow the instructions in Before You Begin .
2. Align the tabs on the optical-drive bezel with the slots on the optical drive and snap the optical-drive bezel into place.
3. Align the screw holes on the optical-drive bracket with the screw holes on the optical drive and replace the two screws.
4. Slide the optical-drive assembly into the optical-drive compartment until it is fully seated.
5. Replace the screw that secures the optical-drive assembly to the computer base.
6. Replace the battery (see Replacing the Battery ).
Back to Contents Page
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
