Adding and Replacing Parts
101
NOTE: Memory modules purchased from Dell are covered under your computer warranty.
3
If you are replacing a memory module, remove the existing module:
a
Use your fingertips to carefully spread apart the securing clips on each end of the
memory module connector until the module pops up.
b
Remove the module from the connector.
4
Ground yourself and install the new memory module.
NOTE: If the memory module is not installed properly, the computer may not boot properly. No
error message indicates this failure.
a
Align the notch in the module edge connector with the tab in the connector slot.
b
Slide the module firmly into the slot at a 45-degree angle, and rotate the module
down until it clicks into place. If you do not feel the click, remove the module and
reinstall it.
securing clips
memory module
