0RGXOH/DWFK$VVHPEOLHV
)LJXUH0RGXOH/DWFK$VVHPEOLHV5HPRYDO
127,&(7RDYRLGGDPDJLQJWKHV\VWHPERDUG\RXPXVWUHPRYHWKH
PDLQEDWWHU\EHIRUH\RXVHUYLFHWKHFRPSXWHU
1. Remove the main battery and secondary battery (if present).
2. Remove the device from the modular bay.
3. Remove the keyboard assembly.
4. Remove the display assembly.
5. Remove the palmrest assembly.
module latches (2)
springs (2)
sliders (2)
module latch button (2)
bottom case assembly
location of
snap tabs (2)
