1
Installation Issues
After Replacing The Hard Drives Or Reinstalling The
Operating System, The RAID Configuration Does Not
Match The Factory Configuration And Defaults To RAID 1
Description After replacing the hard drives or reinstalling the operating system, the RAID
configuration on the system does not match the factory configuration and defaults
to RAID 1.
Cause This issue occurs because the operating system reinstallation media cannot find an
operating system partition of 120 GB or larger on Virtual Disk 0.
Workaround To work around this issue, perform the following steps:
NOTE: The operating system can only be installed on LUN 0 of the internal
controller. To configure a RAID configuration other than RAID 1, create a
virtual disk with LUN ID 0 before reinstalling the operating system.
1. Backup data from all virtual disks.
2. Reboot your system and enter the Dell PowerEdge RAID Controller (PERC)
BIOS.
For more information, see the PERC documentation at dell.com/support/
manuals.
3. Create a virtual disk with the desired RAID configuration, LUN ID 0, and a
capacity of 120 GB or more.
4. Reboot the Dell PowerVault NAS system using the operating system
reinstallation media.
Error: -5000 Shows Unexpected System Error Message
Description A required system resource cannot be located or is faulty.
Cause This issue occurs because either the operating system reinstallation media, optical
drive, or the system is in an invalid state.
Workaround Restart your system and reinstall the operating system reinstallation media. If the
issue persists, contact Dell. For more information, see
Contacting Dell .
Error: -5001 Shows Invalid System Error Message
Description System restore is being performed on an unsupported system.
Cause This issue occurs because the operation is not supported on the system.
5
