I/O and IEEE 1394 Board

Dell Precision™ Workstation M6500 Service Manual

WARNING:

Before working inside your computer, read the safety information that shipped with your

computer. For additional safety best practices information, see the Regulatory Compliance Homepage at

www.dell.com/regulatory_compliance.

Removing the Right I/O Board

Removing the Right I/O Board

NOTE:

You may need to install Adobe® Flash® Player from Adobe.com in order to view the illustrations below.

1. Follow the procedures in

2. Remove the

3. Remove the

4. Remove the

5. Remove the

6. Remove the

7. Remove the

8. Remove the

9. Remove the four screws that secure the right I/O board to the chassis.
