Adding and Replacing Parts
97
2 Remove the center control cover:
a Open the display all the way (180 degrees) so that it lies flat against your work surface.
b Starting on the right side of the computer, use a plastic scribe to pry up the center control
cover. Lift it away from the computer, and lay it aside.
3 Remove the keyboard:
a Remove the two M2.5 x 5-mm screws across the top of the keyboard.
NOTICE:
The keycaps on the keyboard are fragile, easily dislodged, and time-consuming to replace. Be
careful when removing and handling the keyboard.
b Rotate the keyboard up and slide it forward.
c Hold the keyboard up and slightly forward to allow access to the keyboard connector.
center control cover
