Installing the RGB Display Panel
1. Align the display bracket with the display panel and tighten the screws
securing the display bracket in place.
2. Connect the Low-voltage Differential Signaling (LVDS) cable to the back of
the display panel and replace the adhesives securing the LVDS cable in
place.
3. Connect the RGB cable to the back of the display panel and replace the
adhesives securing the RGB cable in place.
4. Tighten the screws securing the display panel in place.
5. Tighten the screws on the left side of the display panel securing the display
panel in place.
6. Install the touch screen display bezel .
7. Install the battery .
8. Follow the procedures in After Working Inside Your Computer .
Removing The Touchscreen Display Panel
1. Follow the procedures in Before Working On Your Computer .
2. Remove the battery .
3. Remove the touchscreen display bezel .
4. Remove the screws on the left side securing the display panel in place. The
screws are partially hidden by the cables. Lift up the cables before
removing the screws.
