21 328D LCR Hydraulic Excavator specifications
R3.2CB2 STICK – 3200 mm (10'6")
BUCKET – 1.2 m
3 (1.57 yd 3 )
UNDERCARRIAGE – Long
SHOES – 850 mm (34") triple grouser BOOM – Reach
HEAVY LIFT – Off
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with SAE hydraulic excavator lift capacity rating standard J1097.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. Weight of all lifting accessories must be deducted from the above
lifting capacities.
1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft) 9.0 m (30.0 ft)
m
ft
9.0 m kg *3000 *3000 7.85
30.0 ft lb *6,650 *6,650 25.27
7.5 m kg *4850 *4850 *2800 *2800 9.05
25.0 ft lb *10,690 *10,690 *6,170 *6,170 29.43
6.0 m kg *6650 *6650 *6200 5400 *2700 *2700 9.80
20.0 ft lb *14,450 *14,450 *13,660 11,550 *5,950 *5,950 32.04
4.5 m kg *9400 *9400 *7650 *7650 *6700 5250 *4700 3750 *2750 *2750 10.24
15.0 ft lb *20,200 *20,200 *16,600 *16,600 *14,550 11,250 *10,360 8,260 *6,060 *6,060 33.55
3.0 m kg *12 050 11 400 *8950 7250 *7350 5050 *6150 3650 *2850 2800 10.40
10.0 ft lb *25,850 24,550 *19,300 15,550 *15,900 10,800 *13,550 8,040 *6,300 6,200 34.12
1.5 m kg *14 100 10 550 *10 050 6850 *7950 4850 6350 3550 *3100 2800 10.30
5.0 ft lb *30,400 22,750 *21,750 14,700 *17,200 10,350 13,650 7,820 *6,800 6,200 33.82
Ground kg *5700 *5700 *14 900 10 100 *10 700 6550 *8300 4650 *6300 3500 *3450 2950 9.94
Line lb *13,000 *13,000 *32,250 21,750 *23,150 14,050 *17,950 10,000 *12,700 7,710 *7,600 6,500 32.62
–1.5 m kg *6150 *6150 *9700 *9700 *14 600 10 000 *10 700 6400 *8200 4600 *4050 3300 9.29
–5.0 ft lb *13,700 *13,700 *21,950 *21,950 *31,600 21,450 *23,100 13,750 *17,700 9,800 *8,950 7,300 30.43
–3.0 m kg *10 400 *10 400 *15 000 *15 000 *13 300 10 050 *9900 6450 *7350 4600 *5100 4100 8.26
–10.0 ft lb *23,300 *23,300 *34,100 *34,100 *28,700 21,600 *21,250 13,800 *15,650 9,900 *11,300 9,050 26.97
–4.5 m kg *14 500 *14 500 *10 700 10 300 *7800 6600 *4350 *4350 6.66
–15.0 ft lb *31,050 *31,050 *22,850 22,150 *16,450 14,250 *9,590 *9,590 21.59
Load at
Maximum Reach Load Point
Height Load Radius
Over Front Load Radius
Over Side
Reach Boom Lift Capacities
R3.2CB2 STICK – 3200 mm (10'6")
BUCKET – 1.2 m
3 (1.57 yd 3 )
UNDERCARRIAGE – Long
SHOES – 850 mm (34") triple grouser BOOM – Reach
HEAVY LIFT – On
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with SAE hydraulic excavator lift capacity rating standard J1097.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. Weight of all lifting accessories must be deducted from the above
lifting capacities.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft) 9.0 m (30.0 ft)
m
ft
9.0 m kg *3100 *3100 7.85
30.0 ft lb *6,900 *6,900 25.27
7.5 m kg *5000 *5000 *2900 *2900 9.05
25.0 ft lb *9,950 *9,950 *6,350 *6,350 29.43
6.0 m kg *6900 *6900 *6450 5400 *2800 *2800 9.80
20.0 ft lb *15,000 *15,000 *13,950 11,550 *6,200 *6,200 32.04
4.5 m kg *9700 *9700 *7950 7650 *6950 5250 *4900 3750 *2850 *2850 10.24
15.0 ft lb *20,900 *20,900 *17,200 16,500 *15,100 11,250 *10,800 8,260 *6,250 *6,280 33.55
3.0 m kg *12 450 11 400 *9250 7250 *7650 5050 *6350 3650 *3000 2800 10.40
10.0 ft lb *26,750 24,550 *20,000 15,550 *16,550 10,800 *13,650 8,040 *6,610 6,200 34.12
1.5 m kg *14 600 10 550 *10 450 6850 *8250 4850 6350 3550 *3200 2800 10.30
5.0 ft lb *31,500 22,750 *22,550 14,700 *17,850 10,350 13,650 7,820 *7,050 6,150 33.82
Ground kg *5900 *5900 *15 450 10 100 *11 100 6550 8400 4650 *6300 3500 *3600 2950 9.94
Line lb *13,450 *13,450 *33,400 21,750 *24,000 14,050 18,000 10,000 *13,100 7,710 *7,900 6,500 32.62
–1.5 m kg *6350 *6350 *10 000 *10 000 *15 100 10 000 *11 100 6400 8300 4600 *4200 3300 9.29
–5.0 ft lb *14,200 *14,200 *22,650 *22,650 *32,750 21,450 *23,950 13,750 17,800 9,800 *9,250 7,300 30.43
–3.0 m kg *10 750 *10 750 *15 500 *15 500 *13 750 10 050 *10 250 6450 *7650 4600 *5300 4100 8.26
–10.0 ft lb *24,050 *24,050 *35,150 *35,150 *29,750 21,600 *22,100 13,800 *16,300 9,900 *11,700 9,050 26.97
–4.5 m kg *15 050 *15 050 *11 100 10 300 *8100 6600 *4550 *4550 6.66
–15.0 ft lb *32,250 *32,250 *23,750 22,150 *17,100 14,250 *10,030 *10,030 21.59
