17 328D LCR Hydraulic Excavator specifications
328D LCR Bucket and Stick Forces
Power Buckets
R3.2CB2 R2.65CB2
Stick R3.2CB2 w/Coupler R2.65CB2 w/Coupler
Bucket Digging Force (ISO) 200 kN 44,962 lb 162 kN 36,419 lb 201 kN 45,187 lb 162 kN 36,419 lb
Stick Digging Force (ISO) 133 kN 29,900 lb 125 kN 28,101 lb 152 kN 34,171 lb 142 kN 31,923 lb
Bucket Digging Force (SAE) 176 kN 39,566 lb 157 kN 35,295 lb 176 kN 39,566 lb 157 kN 35,295 lb
Stick Digging Force (SAE) 129 kN 29,000 lb 124 kN 27,876 lb 147 kN 33,047 lb 141 kN 31,698 lb
HD and HDR Buckets
R3.2CB2 R2.65CB2
Stick R3.2CB2 w/Coupler R2.65CB2 w/Coupler
Bucket Digging Force (ISO) 179 kN 40,241 lb 155 kN 34,845 lb 180 kN 40,466 lb 155 kN 34,845 lb
Stick Digging Force (ISO) 130 kN 29,225 lb 123 kN 27,651 lb 149 kN 33,497 lb 139 kN 31,248 lb
Bucket Digging Force (SAE) 159 kN 35,745 lb 142 kN 31,923 lb 159 kN 35,745 lb 142 kN 31,923 lb
Stick Digging Force (SAE) 126 kN 28,326 lb 120 kN 26,977 lb 143 kN 32,148 lb 136 kN 30,574 lb
Major Component Weights
Base machine with counterweight (without front linkage) with 850 mm (34") shoe 29 700 kg 65,477 lb
Two boom cylinders (each) 240 kg 529 lb
Counterweight
Standard counterweight 7720 kg 17,020 lb
Boom (includes lines, pins and stick cylinder)
Reach boom 6.15 m (20'2") 2300 kg 5,071 lb
Stick (includes lines, pins, bucket cylinder and linkage)
R3.2CB2 m (10'6") 1390 kg 3,064 lb
R2.65CB2 m (8'8") 1300 kg 2,866 lb
* All weights are approximate.
