CAT Hydraulic Excavator 328D LCR - Manual (Page 20)

R2.65CB2 STICK – 2650 mm (8'8")
BUCKET – 1.2 m
3 (1.57 yd 3 )
UNDERCARRIAGE – Long
SHOES – 850 mm (34") triple grouser BOOM – Reach
HEAVY LIFT – Off
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with SAE hydraulic excavator lift capacity rating standard J1097.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. Weight of all lifting accessories must be deducted from the above
lifting capacities.
3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft) 9.0 m (30.0 ft)
m
ft
9.0 m kg *3950 *3950 7.16
30.0 ft lb *8,750 *8,750 22.96
7.5 m kg *6900 *6900 *3600 *3600 8.48
25.0 ft lb *15,200 *15,200 *7,950 *7,950 27.56
6.0 m kg *7350 *7350 *6800 5350 *3500 *3500 9.30
20.0 ft lb *16,000 *16,000 *14,900 11,400 *7,700 *7,700 30.37
4.5 m kg *10 550 *10 550 *8350 7600 *7200 5250 *3550 3300 9.76
15.0 ft lb *22,600 *22,600 *18,050 16,300 *15,650 11,200 *7,750 7,250 31.97
3.0 m kg *13 050 11 200 *9550 7200 *7750 5050 *5150 3650 *3650 3100 9.93
10.0 ft lb *28,050 24,100 *20,600 15,450 *16,850 10,800 *8,050 6,850 32.58
1.5 m kg *14 700 10 450 *10 500 6850 *8250 4850 *5800 3600 *3950 3100 9.83
5.0 ft lb *31,750 22,500 *22,650 14,700 *17,850 10,400 *8,650 6,850 32.26
Ground kg *15 000 10 150 *10 900 6600 8450 4750 *4350 3300 9.45
Line lb *32,550 21,800 *23,600 14,200 18,100 10,150 *9,600 7,250 31.00
–1.5 m kg *9900 *9900 *14 300 10 100 *10 650 6500 *8150 4700 *5100 3750 8.75
–5.0 ft lb *22,500 *22,500 *30,950 21,700 *22,950 14,000 *17,450 10,050 *11,200 8,300 28.66
–3.0 m kg *16 750 *16 750 *12 550 10 250 *9450 6600 *5350 4750 7.63
–10.0 ft lb *36,350 *36,350 *27,150 22,000 *20,300 14,150 *11,650 10,550 24.90
–4.5 m kg *12 150 *12 150 *9350 *9350 *6400 *6400 *6150 *6150 6.09
–15.0 ft lb *25,950 *25,950 *19,850 *19,850 *13,450 *13,450 19.72
Load at
Maximum Reach Load Point
Height Load Radius
Over Front Load Radius
Over Side
Reach Boom Lift Capacities
R2.65CB2 STICK – 2650 mm (8'8")
BUCKET – 1.2 m
3 (1.57 yd 3 )
UNDERCARRIAGE – Long
SHOES – 850 mm (34") triple grouser BOOM – Reach
HEAVY LIFT – On
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with SAE hydraulic excavator lift capacity rating standard J1097.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. Weight of all lifting accessories must be deducted from the above
lifting capacities.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft) 9.0 m (30.0 ft)
m
ft
9.0 m kg *4050 *4050 7.16
30.0 ft lb *9,050 *9,050 22.96
7.5 m kg *7150 *7150 *3750 *3750 8.48
25.0 ft lb *15,750 *15,750 *8,250 *8,250 27.56
6.0 m kg *7650 *7650 *7050 5350 *3650 *3650 9.30
20.0 ft lb *16,600 *16,600 *15,450 11,400 *8,000 *8,000 30.37
4.5 m kg *10 900 *10 900 *8650 7600 *7450 5250 *3650 3300 9.76
15.0 ft lb *23,400 *23,400 *18,700 16,300 *16,250 11,200 *8,050 7,250 31.97
3.0 m kg *13 500 11 200 *9900 7200 *8050 5050 *5350 3650 *3800 3100 9.93
10.0 ft lb *29,050 24,100 *21,350 15,450 *17,450 10,800 *8,350 6,850 32.58
1.5 m kg *15 250 10 450 *10 900 6850 *8550 4850 *6000 3600 *4100 3100 9.83
5.0 ft lb *32,900 22,500 *23,500 14,700 18,450 10,400 *8,950 6,850 32.26
Ground kg *15 550 10 150 *11 300 6600 8450 4750 *4500 3300 9.45
Line lb *33,700 21,800 *24,450 14,200 18,100 10,150 *9,950 7,250 31.00
–1.5 m kg *10 250 *10 250 *14 800 10 100 *11 000 6500 8400 4700 *5250 3750 8.75
–5.0 ft lb *23,250 *23,250 *32,100 21,700 *23,850 14,000 18,050 10,050 *11,600 8,300 28.66
–3.0 m kg *17 150 *17 150 *13 050 10 250 *9800 6600 *5550 4750 7.63
–10.0 ft lb *37,700 *37,700 *28,150 22,000 *21,050 14,150 *12,150 10,550 24.90
–4.5 m kg *12 650 *12 650 *9750 *9750 *6700 *6700 *6400 *6400 6.09
–15.0 ft lb *27,000 *27,000 *20,650 *20,650 *14,000 *14,000 19.72
20 328D LCR Hydraulic Excavator specifications
