328D LCR Bucket Specifications and Compatibility
Bucket Type Adaptor Capacity Width Tip Radius Teeth Total Weight Reach Stick
m 3 yd 3 mm in mm in Qty kg lb R3.2CB2 R2.65CB2
CB2 Buckets
General Purpose
K90 0.63 0.82 610 24 1656.3 65.2 3 729 1606
s s
K90 0.86 1.12 762 30 1656.3 65.2 4 847 1868
s s
K90 1.09 1.43 914 36 1656.3 65.2 5 951 2097
s s
K90 1.34 1.75 1067 42 1656.3 65.2 5 1024 2258
s s
K90 1.58 2.07 1219 48 1656.3 65.2 6 1121 2471 s s
K90 1.83 2.39 1372 54 1656.3 65.2 7 1218 2684
n s
Heavy Duty K100 0.53 0.69 610 24 1686.3 66.4 3 780 1720
s s
K100 0.73 0.95 762 30 1686.3 66.4 3 858 1891
s s
K100 0.93 1.22 914 36 1686.3 66.4 4 982 2165
s s
K100 1.14 1.49 1067 42 1686.3 66.4 5 1073 2365
s s
K100 1.35 1.77 1219 48 1686.3 66.4 5 1143 2519
s s
K100 1.57 2.05 1372 54 1686.3 66.4 6 1238 2730 s s
K100 1.78 2.33 1524 60 1686.3 66.4 7 1334 2941
n s
K100 1.99 2.60 1676 66 1686.3 66.4 7 1406 3101
* n
Heavy Duty Rock K100 0.73 0.95 762 30 1686.3 66.4 3 965 2127
s s
K100 0.93 1.22 914 36 1686.3 66.4 4 1073 2365
s s
K100 1.14 1.49 1067 42 1686.3 66.4 5 1174 2588
s s
K100 1.35 1.77 1219 48 1686.3 66.4 5 1259 2775
s s
Heavy Duty Power K100 1.12 1.46 1067 42 1592.1 62.7 5 1060 2337
s s
K100 1.33 1.74 1219 48 1592.1 62.7 5 1137 2507
s s
K100 1.53 2.00 1372 54 1592.1 62.7 6 1237 2727
s s
Ditch Cleaning — 1.25 1.63 1524 60 1262.0 49.7 — 739 1629 s s
— 1.53 2.00 1830 72 1262.0 49.7 — 837 1845
s s
s 2100 kg/m 3 (3,500 lb/yd 3 ) max material density
n 1800 kg/m 3 (3,000 lb/yd 3 ) max material density
* 1500 kg/m
3 (2,500 lb/yd 3 ) max material density
∴ 1200 kg/m 3 (2,000 lb/yd 3 ) max material density
— Not Available
Assumptions for maximum material density rating:
1. Front linkage fully extended at ground line
2. Bucket curled
3. 100% bucket fill factor
* Capacities based on SAE J296. Some calculations of capacity fall on borderlines.
Rounding may allow two buckets to have the same English rating but different metric ratings.
18 328D LCR Hydraulic Excavator specifications
