Keyboard
Dell™ Latitude™ C840 Service Manual
Removing the Keyboard
1. Follow the instructions in " Preparing to Work Inside the Computer ."
2. Turn the computer over and remove the four M2.5 x 20-mm screws (three labeled "circle K" and one labeled "circle K/M").
3. Turn the computer over and open the display.
4. Use a nonmarring plastic scribe under the blank key to pry up the keyboard.
NOTICE: Disconnect the computer and attached devices from electrical outlets and remove any installed batteries.
NOTICE: To avoid ESD, ground yourself by using a wrist grounding strap or by periodically touching unpainted metal on the computer.
1 M2.5 x 20-mm screws (4)
NOTICE: Be careful when handling the keyboard. The keycaps are fragile, easily dislodged, and time-consuming to replace.
