106 Antenna Module(s)
Replacing the Antenna Module(s)
Procedure
1 Align the screw holes on the antenna modules with the screw holes
on the chassis.
2 Replace the screws that secure the antenna modules to the chassis.
3 Route the antenna cables through the routing guides on the chassis.
Postrequisites
1 Follow the instructions from step 1 to step 3 in "Replacing the System
Board" on page 101.
2 Replace the I/O board shield.
See "Replacing the I/O Board Shield" on page 82.
3 Replace the power-supply fan bracket.
See "Replacing the Power-Supply Fan Bracket" on page 73.
4 Replace the I/O cover. See "Replacing the I/O Cover" on page 77.
5 Replace the wireless mini-card.
See "Replacing the Wireless Mini-Card" on page 53.
6 Replace the memory modules.
See "Replacing the Memory Module(s)" on page 35.
7 Replace the system-board shield.
See "Replacing the System-Board Shield" on page 49.
8 Follow the instructions from step 4 to step 8 in "Replacing the Hard Drive"
on page 46.
9 Replace the VESA-mount bracket.
See "Replacing the VESA-Mount Bracket" on page 42.
10 Replace converter board. See "Replacing the Converter Board" on page 29.
11 Replace power-button board.
See "Replacing the Power-Button Board" on page 32.
12 Follow the instructions from step 4 to step 6 in "Replacing the Optical
Drive" on page 40.
13 Replace the back cover. See "Replacing the Back Cover" on page 22.
