30
DPM Reinstallation
Run each software component shown in Table 6-1 by double-clicking each
executable file, in the order shown.
Installing Windows Deployment Services (WDS) on PowerVault DP100 Systems
Prior to installing DPM on a PowerVault DP100 system, you must install the
Windows Deployment Services (WDS) by following the steps below. (If you
are installing DPM on a PowerVault DP500 or DP600, this step is not
necessary.)
1 Click Start→ Control Panel→ Add or Remove Programs→ Add/Remove
Windows Components.
2 Select Windows Deployment Services and click Next.
3 When prompted to insert the Service Pack 2 CD, insert the Microsoft
Windows Storage Server 2003 R2, Workgroup Edition x64 with SP2 Disk 1 of
2 CD and point to the appropriate drive.
4 When prompted to insert the Windows Server 2003 Standard x64 Edition
CD, insert the Microsoft Windows Storage Server 2003 R2, Workgroup
Edition x64 with SP2 Disk 1 of 2 CD.
5 When prompted to restart the computer, remove the CD and click Yes.
Prerequisite Network Configuration
To install DPM, the following network configuration requirements must be
met. Contact your network administrator if you need assistance meeting
these requirements.
• Your system must be on a network and have a valid IP address.
• Your system must be a member of a domain.
Table 6-1. DPM Prerequisite Software
Prerequisite hotfixes Location on the DPM reinstallation
media
PowerShell 1.0 \prereqs\KB926139-x64-ENU.exe
PowerShell MUI pack \prereqs\ KB926141-x64-ENU.exe
Hotfix KB940349 \prereqs\KB940349-v3-x64-
ENU.exe
