Page 7: Removing the expresscard cage
Removing the Modem Connector
1.
Follow the instructions in
Before You Begin
.
2.
Remove the modem (see
Removing the Modem
).
3.
Remove the system board (see
Removing the System Board Assembly
).
4.
Remove the M2.5 x 5-mm screw that secures the modem connector to the base of the computer.
5.
Lift the modem connector out of the computer.
Replacing the Modem Connector
1.
Align the screw hole in the modem connector with the screw hole in the base of the computer, and then lower the connector into place.
2.
Replace the M2.5 x 5-mm screw and secure the modem connector to the base of the computer.
3.
Replace the system board (see
Replacing the System Board Assembly
).
4.
Replace the modem (
Replacing the Modem
).
ExpressCard Cage
Removing the ExpressCard Cage
CAUTION:
Before you begin the following procedure, follow the safety instructions in the Product Information Guide.
NOTICE:
Before you remove the modem connector, observe how the cable is routed on the base of the computer to ensure proper installation when
the connector is replaced.
CAUTION:
Before you begin the following procedure, follow the safety instructions in the Product Information Guide.
NOTICE:
Ensure that the modem connector cable is properly routed before replacing the system board.
CAUTION:
Before you begin the following procedure, follow the safety instructions in the Product Information Guide.
