Dell Dimension L___cx - Manual (Page 32)

Internally accessible
Primary EIDE 40-pin connector on PCI bus
Secondary EIDE 40-pin connector on PCI bus
Diskette drive 34-pin connector
2 Present only on systems with integrated audio and network capabilities.
Video
Video controller
Dimension Lxxxr and Lxxxcx Intel 810e chip set with Dynamic Video Memory and 4-MB display cache memory
Dimension Lxxxcxe Intel 810 chip set with Dynamic Video Memory
Dimension Lxxx c Intel 810 chip set with Dynamic Video Memory and 4-MB display cache memory
Audio
Audio controller 2 Creative Sound Blaster Audio PCI chip with 64-voice wavetable synthesis
2 Present only on systems with integrated audio and network capabilities.
Network
NIC
2 Intel Pro 10/100-Mbps 82559 chip
2 Present only on systems with integrated audio and network capabilities.
Power
DC power supply
Wattage 145 W
Heat dissipation 700 BTU (fully loaded system without monitor)
Voltage (switch selectable on back
panel) 90 to 135 V at 60 Hz;
180 to 265 V at 50 Hz;
100 V at 50 to 60 Hz for Japanese systems
Backup battery 3-V CR2032 coin cell
Physical
Height 39 cm (15.375 inches)
Width 16.8 cm (6.625 inches)
Depth 34 cm (13.375 inches)
Weight 9.9 kg (22 lb)
Environmental
Temperature
Operating
10° to 35°C (50° to 95°F)
3
