96
Installing System Components
7 Bend both the card-edge guides outward and pull the storage controller
card out of the connector.
Figure 3-15. Installing and Removing the Storage Controller Card
1 storage connector 2 expansion-card riser
3 storage controller card 4 storage controller card cable
5 SAS data cable connector 6 release lever (blue)
1
2
3
6
5
4
