Replacing the System Board
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before Working Inside Your Computer . After working inside your
computer, follow the instructions in After Working Inside Your
Computer . For more safety best practices, see the Regulatory
Compliance home page at dell.com/regulatory_compliance.
NOTE: Your computer’s Service Tag is stored in the system board. You
must enter the Service Tag in the system setup after you replace the
system board.
Procedure
1 Slide the ports on the system board into the slots on the display-panel
base and align the screw holes on the system board with the screw holes
on the display-panel base.
2 Replace the screws that secure the system board to the display-panel
base.
3 Connect the fan cable, optical-drive cable, hard-drive cable, hard-drive
and optical-drive power cable, converter-board cable, control-buttons
board cable, speaker cable, and camera cable to the system board.
For more information, see
System Board Components .
4 Slide the display cable in the connector on the system board and press
down on the latch to secure the cable.
Postrequisites
1 Replace the heat sink .
2 Replace the wireless card .
3 Replace the system-board shield .
4 Replace the memory module(s) .
5 Replace the VESA-mount bracket .
6 Replace the back cover .
7 Replace the stand assembly .
